BASIC INFO
Testo 616 - Moisture meter Order-NO: 0560 6160
Measures moisture in wood / building materials
Non-destructive / precise measurements up to 2 in.
10 characteristic curves for different types of building material / wood
Backlit display / hold function / min/max memory / ergonomic design
The testo 616 professional moisture meter provides you with a precise and non-destructive means of measuring the moisture content of wood and other building materials.
Product Description
The testo 616 professional moisture meter provides you with a precise and non-destructive means of measuring moisture in wood and building materials, and of monitoring the drying process after water damage. Simply select the characteristic curve, and place the meter’s measuring claw against the material’s surface. The meter shows the moisture content as a weight percentage compared to the dry weight. Press the relevant key to save the reading to your meter.
Although the measuring claw only comes into contact with the surface, wall or flooring, it is able to determine the moisture content of the wood or other material down to a depth of 2 in.
Ideal areas of use for the testo 616 moisture meter
The testo 616 moisture meter is a professional measuring device that can be used in areas as diverse as water damage restoration, or carpentry or joinery.
Moisture damage detection: the non-destructive method for finding moisture in walls / floors
Monitoring drying processes: from carrying out moisture inspections, to meeting building schedules, to controlled drying after water damage – the non-destructive method for determining the moisture content in wood / building materials
Moisture in wood: for checking for moisture in wood that has been stored prior to processing
testo 616 moisture meter with 10 characteristic curves
Soft wood
Hard wood
Pressboard
Anhydrite screed
Cement screed
Lime sand brick
Gas concrete
Concrete
High insulation bricks
Brickwork
Delivery Scope
testo 616 moisture meter for wood and building materials, calibration certificate, and batteries
| Humidity - Capacitive | |
|---|---|
|
Measuring range |
< 50 % (wood) < 20 % (building materials) |
|
Resolution |
0.1 |
| General technical data | |
|---|---|
|
Dimensions |
3 x 2 x 9 in. / 70 x 58 x 234 mm |
|
Operating temperature |
41.0° to 104.0 °F / +5 to +40 °C |
|
Housing |
ABS / TPE / Metal |
|
Protection class |
IP30 |
|
Battery type |
9V block battery, 6F22 |
|
Battery life |
60 h |
|
Display update |
0.5 s |
|
Measuring rate |
0.5 sec |
|
Unit |
Water content in percent by weight based on dry mass (%) |
|
Measurement depth |
up to 5 cm |
|
Storage temperature |
-4.0° to 158.0 °F / -20 to +70 °C |
|
Weight |
9 oz. / 260 g |
